| Parts List - (Items Included) |
|
| Part Number | Qty | Description |
| Motherboard / Chassis | MBD-X11DPG-OT-CPU | 1 | Super X11DPG-OT-CPU Motherboard |
| MBD-X10DRG-O-PCIE | 1 | Super X10DRG-O-PCIE Motherboard |
| CSE-418GTS-R4000BP2 | 1 | CSE-418GTS-R4000BP2 Chassis |
| Backplane | BPN-SAS3-216A-N4 | 1 | 24-port 2U SAS3 12Gbps hybrid backplane, support up to 20x 2.5-inch SAS3/SATA3 HDD/SSD and 4x SAS3/SATA3/NVMe Storage Devices |
| Cable 1 | CBL-0449L | 2 | HDD power extension for X8OBN, special 8 pin to 4 HDD. 45cm. 18AWG |
| Cable 2 | CBL-PWEX-1028 | 8 | GPU,2x4F/CPU to 2x4F/CPU,P4.2, 30CM,16AWG, 10A/pin, -40~105C |
| Cable 3 | CBL-SAST-0507-01 | 2 | MINI SAS HD-MINI SAS,6G,INT,80CM,SB,28AWG |
| Cable 4 | CBL-SAST-0972 | 2 | OcuLink V. 1.0 source to MiniSAS HD,INT,PCIe, 70CM,34AWG,RoH |
| Parts | MCP-130-41802-0B | 1 | Black plastic palm cover for X10DRG-O-PCIE |
| Riser Card | RSC-X9DRG-O | 4 | RSC-X9DRG-O |
| Heatsink / Retention | SNK-P0068APS4 | 2 | 2U Active CPU Heat Sink Supporting Narrow Bolster Plate Mounting Mechanism for X11 Purley Platform |
| Power Supply | PWS-2K05A-1R | 4 | 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH |
| FAN 1 | FAN-0199L4 | 8 | 92x92x38 mm, 11.5K RPM, SC418G Middle Fan w/ Housing,RoHS/REACH,PBF |
| Rear Window | MCP-240-84802-0N | 1 | 21 slot rear window for SC418X |
|
| Optional Parts List |
|
| Part Number | Qty | Description |
| 0.5U LID | MCP-230-41803-0N | 1 | Top cover for GTX card support |
| 1U LID | MCP-230-41806-0N | 1 | Top cover for NVLINK BRIDGE support |
| 2.5" NVMe Drive Trays | MCP-220-00121-0B | 1 per drive | Black Gen-3 2.5" NVMe drive tray. Orange tab with lock |
| MCP-220-00167-0B | Black Gen-3 2.5" NVMe drive tray. Orange tab with lock, Tool-less |
|
|
| GPU Dummy Tray | MCP-240-00096-0N | 1 | GPU / Add-on Card Dummy Assembly (2 Slots) |
| GPU Cables | CBL-PWEX-0665 | 1 per GPU*** | GPU power cable (for NVIDIA P40, M40, M60, AMD MI25). 8pin FEMALE BLK to 8pin FEMALE WHT. 30cm 18AWG. |
| CBL-PWEX-1017 | 1 per GPU | GPU power cable (for NVIDIA QUADRO, GTX). 8pin FEMALE CPU BLUE to 2x 6pin FEMALE / 2x 1pin FEMALE. 20cm 16AWG/20AWG. |
| CBL-PWEX-1040* | 1 per GPU | GPU power cable (for NVIDIA QUADRO, GTX). 8pin MALE CPU to 2x 6pin FEMALE / 2x 1pin FEMALE. 5cm 20AWG/16AWG. |
| CBL-PWEX-1028** | 1 per GPU | GPU power cable (for NVIDIA TESLA V100). 8pin FEMALE CPU BLUE to 8pin FEMALE CPU BLUE. 30cm 20AWG/16AWG. |
| Note: | * Use with CBL-PWEX-1028 |
| ** 8 qty. included with each system |
| *** 2 qty. required for each MI25 |
| Storage Control Cards and Cables | AOC-S3008L-L8I2 | 1 | Broadcom 3008 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,1E,10 |
| AOC-S3008L-L8E2 | 1 | Broadcom 3008 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, HBA only |
| AOC-S3108-H8IR2, 4, 8 | 1 | Broadcom 3108 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60 |
| AOC-S3108L-H8IR-16DD4, 8 | 1 | Broadcom 3108 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. Maximum 16 HDD support with expander backplane |
| AOC-SAS3-9361-16I3, 5 | 1 | Broadcom 9361 STD LP 16 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. |
| AOC-SAS3-9361-24I5, 6 | 1 | Broadcom 9361 STD LP 24 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. |
| CBL-SAST-0531 | 2 | n/a |
| BTR-TFM4G-LSI004187 | 1 | LSI Remote CVKit with DVFlash Module CVFM04 for 9361 and 9380 Controller Series |
| BTR-TFM8G-LSICVM02 | 1 | LSI Supercap w/ 8GB CV + 24" cable for LSI S3108-H8IR. |
| Optional installation kit: |
| - MCP-240-00127-0N |
| - BKT-BBU-BRACKET-05 |
| MCP-240-00127-0N | 1 | Remote Mounting Bracket for Supercap. Installs in 2.5" drive tray. |
| BKT-BBU-BRACKET-05 | 1 | Remote Mounting Board for Supercap. Full Height mounting bracket. Low Profile mounting bracket also included. |
| BPN-SAS3-216EL1 | 1 | SAS3 12Gb/s Single Expander Backplane with x24 2.5" SATA/SAS HDD/SSD. |
| Note: | 2. Requires x2 CBL-SAST-0531 |
| 3. Requires x4 CBL-SAST-0531 |
| 4. Use BTR-TFM8G-LSICVM02 for Supercap |
| 5. Use BTR-TFM4G-LSI00418 for Cache Vault |
| 6. Requires x6 CBL-SAST-0531 |
| 7. Requires BKT-BBU-BRACKET-05 |
| 8. Optional BPN-SAS3-216EL1 Expander Backplane support. Will lose x2 U.2 NVMe support |
| Network and Cables | AOC-STG-i4S | 1 | 4 Port 10G SFP+ PCI-E x8 Ethernet card. Based on Intel X710-AMI |
| AOC-STG-i2T | 1 | 2 Port 10G RJ45 PCI-E x8 Ethernet card. Based on Intel X540 |
| AOC-S25G-B2S | 1 | 2 Port 25G SFP28 PCI-E x8 Ethernet card. Based on Broadcom BCM57414 |
| AOC-S25G-M2S | 1 | 2 Port 25G SFP28 PCI-E x8 Ethernet card. Based on Mellanox ConnectX-4 LX EN |
| AOC-MCX4121A-ACAT | 1 | 2 Port 25G SFP28 PCI-E X8 Ethernet card. Based on Mellanox ConnectX-4 LX EN |
| AOC-S40G-I1Q | 1 | 1 Port 40G QSFP+ PCI-E X8 Ethernet card. Based on Intel X710 |
| AOC-S40G-I2Q | 1 | 2 Port 40G QSFP+ PCI-E X8 Ethernet card. Based on Intel X710 |
| AOC-MCX456A-ECAT | 1 | 2 Port 100G QSFP28 PCI-E X16 EDR IB card. Based on Mellanox Connect-4 VPI |
| AOC-MCX556A-ECAT | 1 | 2 Port 100G QSFP28 PCI-E X16 EDR IB card. Based on Mellanox Connect-5 VPI |
| CBL-NTWK-0944-MS28C30M | 1 | Ethernet Cable, SFP28,28GbE,PASSIVE,30 AWG,3M,Mellanox |
| CBL-NTWK-0944-MS28C20M | 1 | Ethernet Cable, SFP28,28GbE,PASSIVE,30 AWG,2M,Mellanox |
| AOC-E10GSFPSR | 1 | Ethernet Transceiver, SFP+ 1000Base-SX / 10GBase-SR |
| CBL-NTWK-0446-01 | 1 | Ethernet Cable, QSFP, 40GbE, PASSIVE, 28 AWG, 3M |
| CBL-NTWK-0942-MQ28E20M | 1 | IB Cable, QSFP28, 100GbE, PASSIVE, 28 AWG, 2M |
| Global Services & Support | OS4HR3/2/1 | - | 3/2/1-year onsite 24x7x4 service |
| OSNBD3/2/1 | - | 3/2/1-year onsite NBD service |
| Software |  SFT-OOB-LIC • | 1 | OOB Management Package (per node license) |
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) |
|
|
